Aluminium Windows – Tilt & Turn / Ventilator
Tilt & Turn Aluminium Windows
Tilt & Turn Window
TECHNICAL INFORMATION
- Frame Construction Depth: 60mm
- Locking System: Multipoint
- Glass Range: 6mm to 32mm
- Corner Details: 45 degree cut, joint with corner connector
- Sealing Overlap: 6mm (Sealing with Gasket)
- Window Height (Max.): 2400mm
- Window Width (Max.): 900mm
- Finishes: Powder/Wood/Anodizing
Top Hung Windows
TECHNICAL INFORMATION
- Frame Construction Depth: 60mm
- Locking System: Multipoint
- Glass Range: 6mm to 32mm
- Corner Details: 45 degree cut, joint with corner connector
- Sealing Overlap: 6mm (Sealing with Gasket)
- Window Height (Max.): 2400mm
- Window Width (Max.): 900mm
- Finishes: Powder/Wood/Anodizing
Three Track With Center Fixed Sliding Door
TECHNICAL INFORMATION
- Frame Construction Depth: 68mm, Three Track
- Locking System: Multipoint Cylinder Locking
- Glass Range: 6mm to 28mm
- Slim Interlock: 24mm
- Corner Details: 45 degree cut, joint with corner connector
- Sealing Overlap: 8mm (Sealing with Brush Seal)
- Sash Height (Max.): 3600mm
- Sash Width (Max.): 1600mm
- Finishes: Powder/Wood/Anodizing
